MENU 3.4 HEATING COMFORT
This menu can be used to select a time range for each day of the week in which the
heating circuit is supplied with an increased comfort temperature, e.g. for quick heating
in the morning.
Setting range: One time range for each day of the week
Default: Mo-Su off
Note: See menu 5.5. for the associated temperature settings.
Ex:
0 6 12 18 24
Mo
3.3.1.
We 0 6 12 18 24
3.3.1.
Fr 0 6 12 18 24
3.3.1.
MENU 3.5 HOT WATER ENABLE
This Menu is activated when Dom. Hot water is selected in menu 9.7.2
It can be used to select the daytime mode times for the domestic hot water; three time
periods can be specified for each weekday and copied over to the following days.
Setting range: Three time ranges for each day of the week
Default: Mo-Su 6:00-22:00
Note: See menu 7.2 for the associated temperature settings
MENU 3.6 HOT WATER ANTI-LEGIONELLA
This Menu is activated when Dom. Hot water is selected in menu 9.7.2
It can be used to select a time range for each day of the week
Setting range: One time range for each day of the week
Default: Mo-Su off
Note: See menu 8.5 for the associated temperature settings.
OPERATING MODE, MENU 4
Operating times for heating circuit and hot water,
4. Exit operating mode
manual mode
4.1 Heating circ. Auto
After an interruption of the mains voltage the control-
4.2 Manual
ler automatically returns to the last operating
▲ ▼
mode selected!
Info
The controller works with the set operating times and
the corresponding different reference flow temperature
values only in the automatic mode.
MENU 4.1 HEAT CIRCUIT
Auto = Automatic/Normal mode using the set times.
Continous Day = The set values for day mode are used.
Continous Night = The set values for night mode are used.
Reference Value = Fixed flow temperature regardless of the outdoor temperature. The
desired flow temperature has to be set in menu 4.3.
14
0 6 12 18 24
Tue
3.3.1.
Th 0 6 12 18 24
3.3.1.
14 day reference value = Specific fixed flow temperatures can be set for the next 14
days in menu 4.4. After 14 days, the reference temperature of the 14th day is used
until the operating mode is changed.
Off = Heating circuit is switched off (except Frost protection)
Settings range: Auto, Continous day, Continous night, Reference value, 14 day
reference, Off / Default: Automatic
MENU 4.2 MANUAL
In Manual mode the individual relay outputs and the connected consumers can be
checked for proper functioning and correct assignment.
The operating mode "Manual" may only be used by specialists for brief function
tests, e.g. during commissioning!
Function in manual mode:
The relays and thus the connected consumer are swit-
Manual operation
ched on and off by pressing a key, with no regard to the
1 2 3 Cal
current temperatures and the parameters which have
off off off
R
been set. At the same time, the current measurement
values of temperature sensors are also shown in the
On
display for the purposes of function control.
MENU 4.3 HEAT CIRCUIT REFERENCE
If operating mode "Reference value" is selected, (Menu 4.1), the reference flow tempe-
rature has to be set here, regardless of the curve/outdoor temperature.
Settings range: 10 °C to 75 °C, Default: 30 °C
MENU 4.4 14 DAY REFERENCE
If operating mode "14 day reference value" is selected (Menu 4.1), the reference flow
temperature for each of the 14 days can be set here.
In the first menu 4.4.1 the starting time of the program is shown. To start the program,
hit restart.
Set parameters for the heating circuit.
Hitting "restart" again will reset the 14 day reference program and start it at day 1.
MENU 4.5 DOMESTIC HOT WATER
Auto = The Domestic Hot Water function is activated according to the schedule
in menu 3.5.
On = The Domestic Hot Water function is always on.
Off = The Domestic Hot Water function is always off.
