PLEASE READ THESE INSTRUCTIONS IN FULL BEFORE USING THE CONTROLLER.

ABOUT THE CONTROLLER

The weather compensated integrated Heating Controller Series 90C-2 facilitates effi-
cient use and function control of your heating system. The device is impressive most of
all for its functionality and simple, almost self-explanatory operation.
For each step in the input process the individual entry keys are assigned to appropriate
functions and explained. The controller menu contains headwords for the measured
values and settings, as well as help texts or clearly-structured graphics.
Important characteristics of the series 90C-2:
- Depiction of graphics and texts in a lighted display
- Simple viewing of the current measurement values
- Statistics and monitoring of the system by means of statistical graphics, etc.
- Extensive setting menus with explanations
- Menu block can be activated to prevent unintentional setting changes
- Resetting to previously selected values or factory settings
- Automatic full calibration of valve positions at least once a day and after a power failure or
disruption.
- Mixer valve operation range could be altered 90º/180º or 270º

DISPOSAL AND POLLUTANTS

The unit conforms to the European RoHS directive 2002/95/EC for the restriction of
the use of certain hazardous substances in electrical and electronic equipment.
The device must not be disposed of together with domestic waste. This app-
lies in particular to the printed circuit card. Legislation may demand special
handling of certain components, or it may be desirable from an ecological
point of view. Local and currently valid legislation must be observed.
6
SERIES 90C-2
1
6
1. Optional room sensor can be connected
2. Power output box is prewired
3.
Functional test by means of status display with LED
4. 128x164 dot fully graphical display
5. Self-explanatory operation using softkey buttons
6.
Outdoor sensor
7.
1.5 m power supply cable with plug is ready for connection
8. Sensor boxes are prewired
9. Flow pipe sensor with 1.5 m cable is prewired
10.
20 m cable for sensors is optional
11.
Universalsensor - ∅5mm, 1,5m
12. Adaptor kit ESBE valves VRG, VRB
13. Adaptor kit ESBE valves MG, G, 3F, BIV, 3H, 3HG
2
3
7
9
8
10
8
11
12
13
