ESBE 90C-2 series Handbuch Seite 22

FUNCTION 90C-2
APPL.
PUMP CONTROL HEAT CIRCUIT 1
PUMPCONTR. HEAT CIRCUIT 2
Activated when temperatur at sensor 3 is lower than
8 specified in menu 6.
HEAT SOURCE TEMPERATUR CONTROL
By temperature with heat circuit 1 as reference
PUMP CONTROL HEAT CIRCUIT 1
PUMPCONTR. HEAT CIRCUIT 2
Activated when temperatur at sensor 3 is lower than
9
specified in menu 6.
HEAT SOURCE TEMPERATUR CONTROL
By temperature with heat circuit 1 as reference
PUMP CONTROL HEAT CIRCUIT 1
(Primary heat source)
HEAT PUMP CONTROL
By floating temperatur with heat circuit 1 as reference
10
AUX. HEAT SOURCE CONTROL
by temperatur control
PUMP CONTROL HEAT CIRCUIT 1
DOM HOT WATER CONTROL
by temperatur control
11
HEAT SOURCE TEMPERATURCONTROL CONTROL
By floating temperatur
PUMP CONTROL HEAT CIRCUIT 1
(Primary heat source)
HEAT PUMP CONTROL
By floating temperatur
12
AUX. HEAT SOURCE CONTROL
by valve position
All applicationexamples 1-12 are available on page 257 - 259.
Notes in application examples:
P1 = Output 1 - Pumpcontrol, P2 = Output 2 - Extra function, P3 = Output 3 - Aux. heating
S3 = Sensor 3, S4 = Sensor 4
1* = Sensor box 1, 2* = Sensor box 2
22
ELECTRICAL CONNECTION
Connect pump heat circ1 as P1
Connect pump heat circ 2 as P2
Connect heat source as P3
Connect sensor as sensor 3+4 in sensor box 2
Connect pump heat circ1 as P1
Connect pump heat circ 2 as P2
Connect heat source as P3
Connect sensor as sensor 3+4 in sensor box 2
Connect pump heat circ1 as P1
Connect Heat Pump as P3
Connect Aux.heat source as P2
Connect sensor as sensor 3+4 in sensor box 2
Connect pump heat circ1 as P1
Connect diverting valve as P2
Connect heat source as P3
Connect sensor as sensor 3+4 in sensor box 2
Connect pump heat circ1 as P1
Connect Heat Pump as P3
Connect Aux.heat source as P2
Connect sensor as sensor 3 in sensor box 2
SETTTING
Menu 9.7.2 Select: Heating circ 2
Settings in menu 6.1-6.6
Menu 9.7.1 Select: Temperature
Settings in menu 5.7-5.8
Menu 9.7.2 Select: Heating circ 2
Settings in menu 6.1-6.6
Menu 9.7.1 Select: Temperature
Settings in menu 5.7-5.8
Menu 9.7.1 Select: Temperature
Settings in menu 5.7-5.8
Menu 9.7.2 Select: Dom. Hot Water
Settings in menu 7
Menu 9.7.2 Select: Heating circ 2
Settings in menu 6.1-6.6
Menu 9.7.1 Select: Temperature
Settings in Menu 5.7-5.8
Menu 9.7.2 Select: Heating circ 2
Settings in menu 6.1-6.6
Menu 9.7.1 Select: Position
Settings in menu 9.7.3 – 9.7.5
PAGE
258
259
259
259
259
