STATISTICS, MENU 2

Function control of the system with operating hours,
2. Exit statistics etc.
2.1 Today
For system data statistics it is essential for
the time to be set accurately on the control-
2.2 28 days
ler. Please note that the clock continues to
▲ ▼
OK run for about 24 hours if the mains voltage is
interrupted, and after that has to be reset. Improper
operation or an incorrect time may result in data
being cleared, recorded incorrectly or overwritten.
The manufacturer accepts no liability for the recorded data!
2.1 TODAY (=FLOW TEMPERATURE DURING THE LAST 24 HOURS)
In the graphical overview the characteristics of outdoor-and flow temperature during
the last 24 hours is shown. The right button changes the unit of time and the two left
buttons scroll through the diagram.
2.2 28-DAYS (=FLOW TEMPERATURE DURING THE LAST 28 DAYS)
In the graphical overview the characteristics of the outdoor and flow temperature during
the last 28 days is shown. The right button changes the unit of time (Days) and the two
left buttons scroll through the diagram.
2.3 OUTDOOR 8760H (1YEAR)
Menu 2.3.1 Current year
Menu 2.3.2 Previous year
Menu 2.3.3 2 years ago
xh: ºC hours. Nr of heating hours when heating is
required. ie hours with lower outdoor temp than specified.
xd: ºC days. Nr of heating days when heating is
required. ie days with lower outdoor temp than specified.
2.4 FLOW 8760H (1YEAR)
Menu 2.4.1 Current year
Menu 2.4.2 Previous year
Menu 2.4.3 2 years ago
xh: Nr of hours with flow temp higher than specified.
xd: Nr of days with flow temp higher than specified.
2.5 OPERATING HOURS HEAT CIRCUIT
Menu 2.5.1 Display of operating hours of the circulation pump/aux. heat.
Menu 2.5.2 The date the measurement started.
2.6 OPERATING HOURS DHW
Menu 2.6.1 Display of operating hours of the DHW
Menu 2.6.1 The date the measurement started
2.7 OPERATING HOURS HEAT CIRCUIT 2
Menu 2.7.1 Display of operating hours of the circulation pump
Menu 2.7.2 The date the measurement started.
2.8 OPERATING HOURS HEAT
Menu 2.8.1 Display of operating hours of the aux. heat.
Menu 2.8.1 The date the measurement started
2.9 ERROR MESSAGES
Display of the last three errors in the system with indication of date and time.
2.10 RESET/CLEAR
Resetting and clearing the individual statistics. Selecting " All statistics clears everything
except for the error log.
TIMES, MENU 3
Operating times for heating circuit and hot water setting
the clock.
3. Exit times
The associated temperature reference values
3.1 Time and date
are specified in menu 5 "Settings"!
3.2 Daylight Saving
MENU 3.1 TIME AND DATE
▲ ▼
OK
This menu is used to set the current time and date.
For proper functioning of the controller and statistics
for the system data it is essential for the time to be
set accurately on the controller. Please note that the
clock continues to run for about 24 hours if the mains
voltage is interrupted, and after that has to be reset.
MENU 3.2 DAYLIGHT SAVING
Automaticly adjust clock för daylight savings time.
MENU 3.3 HEATING CIRCUIT DAY
This menu is used to select the daytime mode times for the heating circuit; three time
periods can be specified for each weekday and copied over to the following
days.
Setting range: Three time ranges for each day of the week
Default: Mo-Su 6:00-22:00
Note: See menu 5.6 for the associated temperature settings
Times that are not specified are automatically considered to be nighttime mode. The set
times are only taken into account in the heating circuit operating mode "Automatic".
Ex:
0 6 12 18 24
Mo
3.2.1. 3.2.1.
0 6 12 18 24
We
3.2.1. 3.2.1.
Fr 0 6 12 18 24
3.2.1. 3.2.1.
Su 0 6 12 18 24
3.2.1.
0 6 12 18 24
Tue
0 6 12 18 24
Th
Sa 0 6 12 18 24
