MENU 9.7.5 VALVE DELAY
When aux heat is activated in menu 9.7.1 this menu is unlocked. Time delay before
valves start to move.
Setting range: from 0 to 120 min, default 70 min.
Time counter is resetted when valve position is less than specified position

MENU LOCK, MENU 10

9 Special functions Menu lock" can be used to secure the controller against
unintentional changing and compromise of basic
10 Menu lock
functions.
11 Service data
▲ ▼ The menus listed below remain completely accessible
OK
despite the menu lock being activated, and can be used
to make adjustments if necessary:
1. Measurement
2. Statistics
3. Times
10. Menu lock
11. Service data
MENU 10.1 MENU LOCK INFO
To block the other menus, select "Menu lock on".
To enable the menus again, select "Menu lock off".
Setting range: on, off / default setting: off
SERVICE DATA, MENU 11
Service data" can be used for remote diagnosis by
11.1
90C 2009/09/09 4436 a specialist or the manufacturer in the event of an
error, etc.
outdoor 0°C
11.2
Flow 0°C
11.3
▲ ▼
11.1 11.26
11.2 11.27
11.3 11.28
11.4 11.29
11.5 11.30
11.6 11.31
11.7 11.32
11.8 11.33
11.9 11.34
11.10 11.35
11.11 11.36
11.12 11.37
11.13 11.38
11.14 11.39
11.15 11.40
11.16 11.41
11.17 11.42
11.18 11.43
11.19 11.44
11.20 11.45
11.21 11.46
11.22 11.47
11.23 11.48
11.24 11.49
11.25 11.50
Subject to technical modifications and amendments. The illustrations and description
are not exhaustive.
Enter the values at the time when the
error occurs into the table.
11.51
11.52
11.53
11.54
11.55
11.56
11.57
11.58
11.59
11.60
11.61
11.62
11.63
11.64
11.65
11.66
11.67
11.68
11.69
11.70
11.71
11.72
11.73
11.74
.
19
