2 . K O K O A M I S O H J E E T :
F I G . 1 : P a n e p ä ä y k s i k k ö ( 1 ) l a t t i a l l e j a k i i n n i t ä
k a k k o s y k s i k k ö ( 2 ) a l u s l e v y i l l ä ( Ø 8 ) ( 1 2 ) ,
m u t t e r i l l a ( M 8 ) ( 1 0 ) j a r u u v e i l l a ( 2 x M 8 * 3 8 ) ( 1 1 ) .
T o i s e l t a p u o l e l t a k i i n n i t ä a l u s l e v y l l ä ( Ø 8 ) ( 1 2 ) j a
k u u s i o k o l o r u u v i l l a ( 9 ) .
F I G . 3 : L i i t ä k a h v a t ( 5 ) p ä ä k a p p a l e e s e e n ( 1 ) .
F I G . 5 : L i i t ä n i v e l o s a ( 7 ) p ä ä k a p p a l e e s e e n ( 1 )
p i i r r o k s e n o s o i t t a m a l l a t a v a l l a .
F I G . 2 : Y h d i s t ä k a k s i p u t k e a ( R = o i k e a e t L = v a s e n ) ( 4 )
o i k e i s i i n r e i k i i n s ä .
F I G . 4 : K i i n n i t ä k a h v a t ( 5 ) j a p u t k e t ( 4 ) l i t t e ä n
a l u s l e v y n ( Ø 8 ) ( 1 2 ) , m u t t e r i n ( M 8 ) ( 1 0 ) j a p u l t i n
( 2 x M 8 * 3 8 ) ( 1 1 ) + ( 2 x M 9 * 3 5 ) ( 1 1 ' ) a v u l l a .
F I G . 6 : K i i n n i t ä n i v e l o s a ( 7 ) l i t t e ä n a l u s l e v y n ( Ø 8 )
( 1 2 ) , m u t t e r i n ( 1 3 ) j a k u u s i o k o l o r u u v i l l a ( 9 ) .
