PROFINET connection

Compatible devices
Cable type
Type of serial data transmission
Transmission speed
Protocol
3)
Shielded cables are expressly recommended
16
All devices that are compatible with PROFINET
100BASE­TX
S Termination: Internal
S Network cable: CAT 5 FTP or
3)
CAT 5 STP
S Connector: RJ­45
S Maximum network­segment length:
100 m
Full duplex
100 Mbits/s
