HBK TIM-PN Montageanleitung Seite 86

Power
Low pass filter, 4th order
Runtimes, filter 1
Filter off
100 Hz
10 Hz
1 Hz
0.1 Hz
When HBM torque transducers with integrated speed measurement are used, the
power calculation is adjusted to the runtime
Fig. 14.1 Dimensions
84
Hz 0.1 / 1 / 10 / 100
μs
ms
ms
ms
s
0.944
2.6
26.8
230
3.12
TIM-PN
SPECIFICATIONS
