12 Before commissioning
12.1 Fasten transportation belt
6
Transportation belt
15
Plastic slides
16
Velcro fastener
12.2 Fastening accessories belt
13
Accessories belt with fastener
15
Plastic slidesr
17
Belt fastener
- 28 -
15
909.1869.9-07
15 6
 Thread the transportation belt into the welding machine
and plastic slides. See sequence of the numbering in the
picture.
13
 Thread the accessories belt into the handle and plastic sli-
des. See sequence of the numbering in the picture.
 Plug the belt fasteners together.
Before commissioning
