1 Machine elements
13
Fig. 11: Machine elements
1
Control panel
2
Connection socket torch/electrode holder/component
guide
3
Torch switch socket
4
Gas connection torch
5
Connection socket component guide/electrodeholder
6
Transportation belt
7
Handle (hoisting point)
8
Mains cable holder
9
Main switch
10
Mains cable
2 Explanation of symbols
2.1 Meaning of the symbols in the operati-
on manual
Danger to life and limb!
If the danger warnings are not observed, slight
or severe injury or even death may be result.
Risk of material damage!
If the danger warnings are not observed, da-
mage to workpieces, tools and equipment may
result.
General information!
i i
Designates useful information about the
product and equipment
- 24 -
6
7
8
1
9
2
10
3
11
4
12
5
11
Shielding gas connection
12
Remote control socket
13
Accessories belt
The carrying strap is exclusively for
the transport by a person.
Illustrated or described accessories are par-
i i
tially not included in the scope of deilivery.
Subject to change.
2.2 Meaning of the symbols on the device
Danger!
Read the user information in the operationma-
nual.
Unplug the mains plug!
Always pull out the plug before opening
the housing.Explanation of symbols
