Starting up
Pulse
 Press key button 44 until the symbol for pulsing lights up,
or lights up in combination with symbol slope (LED 35).
 Access the secondary parameter (refer to the subchapter:
accessing secondary parameter).
 Select secondary parameter secondary current I2 (Code „I
2").
 Set the required secondary power value with turning knob
45. The adjusted value is based in % from welding current
I1.
 Select the secondary parameter pulse frequence (Code
„FPU").
 Set the required pulse frequence with turning knob 45.
 Select secondary parameter pulse pause ratio (Code
„bPU").
 Set the required pulse pause ratio with turnng knob 45.
The adjusted value is based in % from welding current I1.
Example: 60% equates to the parts 60% welding current I1
and 40% secondary current I2.
 Exit secondary parameter.
01.22
13.3 Jobs
The 180 AC/DC ControlPro provides 4 jobs which may be pro-
grammed individually. There are 2 jobs available in the elect-
rode mode and TIG mode. One job saves/stores all parameter
and secondary parameter.
All jobs are pre-set ex works with standard values.
Job saving/storing
 Set the welding machine as reqired.
 Press key pad „1" 48 or „2" 46 for at least 3 seconds.
9 LED 49 or LED 47 will light up twice to confirm.
Job selection
 Shortly press key „1" 48 or „2" 46.
9 LED 49 or LED 47 will light up permanently to confirm the
selected job.
Job exit
 Turn knob 45 or press key 40, 42 or 44 shortly.
