10.17
Menù numeri seriali/versioni HW e FW
The indicated data is only indicative
COUNTERS
EVENTS
TIMES
IDVER
ENTER
TARGET:IPU
HW:2
SERN:200000 04/22
R485:1.0 BOOT:1.10
ENTER
TARGET: IPU R1.50
HW: IFW:
SERN:
R485:
ENTER
ESC
R1.50
IFW:02-03
ESC
BOOT:
ESC
Firmware version of the board
TARGET: indicates which device the data below are
being read from.
HW: Hardware version of the board.
IFW:
(*) the IFW value read by the inverter must be in the range
(or equal to the value) read from F70/IPU36. Otherwise,
the INV.FW alarm is triggered (par. 10.5.1)
SERN:
Week/year.
R485: the version of the MODBUS protocol used for
serial communication or via WiFi.
BOOT:
update).
Return to the previous menu
MOT1 or MOT2.
Pressing ESC returns to the main IDVER page, although
those corresponding to MOT1 are displayed (if MOT 1 is
selected) or MOT2 (or F70/IPU36).
