CMD: AP
T
E
SIC: COS1
S
A_IPU --
T
A_M1:-- A_M2:--
ENTER
Back to command input display
ALARMS FOR MOTOR 1 / MOTOR 2
1
Short circuit detected on motor phases
2
Motor overload detected
3
Motor supply voltage too low detected
4
Thermal motor protection activation
5
Motor overtemperature detected
Loss of motor control detected, if it occurs again, motor
6
timing will be necessary
Calibration error in the motor current control.
7
reset of inverter functionality. Contact service
8
EEPROM damaged
9
EEPROM error on stroke length
10 EEPROM error on current mapping
ALARMS F70/IPU36
1
No communication with inverter 1
2
No communication with inverter 2
3
No communication with inverter 1 and 2
4
Output overload 24V
ESC
TEST MODE
Activation of a command or safety is signalled by the
mand does not affect the automation); in the CMD line, the
active command (AP, CH; ...) is highlighted for 5 seconds, whi-
le in the SIC line, the most prioritised safety is in alarm (the
warning disappears when the safety returns to rest).
A_IPU, A_M1 and A_M2 display an alarm number according
to the tables below.
Return to the previous menu
11 No timing data in the inverter EEPROM memory, or
12
13
14 the motor cable (4-wire) from the control unit, wait 10
seconds and then connect it again, checking that the alarm
has disappeared
15 Motor rotor locked (timing impossible)
Motor timing failed, rotor position measurement out of
16
tolerance
Encoder magnet missing or damaged; inverter not correctly
17
positioned or secured on the motor
Motor data incompatibility between inverter and F70/IPU36
18
detected, contact service
Motor model selection is incorrect (model not managed by
19
the inverter)
20 Motor faulty or motor phases not connected
5
Very low supply voltage
6
Overload on braking resistor circuit
7
Mains frequency fault
-
79
