Function buttons and display
When the display is not lit up, press any of the keys around it to reactivate the back-lighting; when it is already lit up,
press a key to navigate the menus and activate automatic switch-off after 5 minuts.
If the display switches off (standby), press the
again on the LCD display.
WARNING: avoid disconnecting and reconnecting the power supply, as this will cause the battery charge
status information to be lost (and only recovered at the end of a complete charging cycle).
It is possible to reset to the standard factory parameters by pressing and holding the
(DOWN ARROW) keys for 4 seconds while starting up the F70/IPU36.
The standard parameters can also be reset by means of parameter
8
Light signals
LED
DESCRIPTION
• Normally off
BATT
• It lights up if the battery is connected to terminals 3, 4 in
L1
• Normally off
•
•
L2
•
•
•
74
BUTTON
DESCRIPTION
Returns to the display of the MENU page / moves the cursor upwards to
select the MENU option
Moves forwards with the display of the MENU page / moves the cursor
downwards to select the MENU option
ENTER
again, it enters the option, allowing to modify it
ESC
Exit from the menu / previous level / saving the set value
+
Value increase
-
Value decrease
and
keys for 5 seconds to reactivate it; the image will appear
REGULAR COMMUNICATION
INVERTER 1 COMMUNICATES REGULARLY
INVERTER 2 DOES NOT COMMUNICATE
INVERTER 1 DOES NOT COMMUNICATE
INVERTER 2 COMMUNICATES REGULARLY
NO COMMUNICATION
WITH INVERTERS
(UP ARROW) and
(see description in paragraph 10.2)
BATT
L1
L2
