Commands and Accessories
If not installed, safety devices with NC contacts must be jumpered at the COM terminals, or disabled by
modifying the parameters
N.C. (Normally Closed).
CONTACT
19(COR)
18 Output (potential free contact) for connecting courtesy light. 230V~ 100 W - 24 V~/
19(COR)
18
15(+LAM)
17(COM)
16(+ES)
15(COM) Input for connecting electric lock, 12V
20(+24V)
21(COM) Power feed for external devices; see table "PRODUCT TECHNICAL FEATURES" on page 69
22(SC)
23(COM) Connection for gate open indicator lamp. 24V
22(SC)
23(COM) Photocell test connection
24(FT2)
23(COM) Input (N.C. or 8.2 kOhm) for connecting photocells FT2
25(FT1)
23(COM) Input (N.C. or 8.2 kOhm) for connecting photocells FT1
72
,
,
,
,
DESCRIPTION
• control unit in alarm / battery supply error (low battery);
•
The COR output operating mode is managed by parameter
The battery level alert can be set-up via parameter
The function of the electric lock is determined by parameter
Vmedia=12V , Vmax=40V ; see table "PRODUCT TECHNICAL FEATURES" on page 69
The control unit includes an electronic limit on the current that may be supplied to the ac-
cessories (like the SC output), this means that, in the event of an overload (or short circuit)
the power supply is disabled for a few seconds (the message 24 V OFF appears on the
display), after which it is restored. This situation should be avoided as there is an irregular
and abnormal operation of the automation system and in the long run it can damage F70/
IPU36.
The function of the indicator lamp is determined by parameter
22(+SC).
Set the parameter
to enable the test function.
Each time a command is received, the control unit switches the photocells off and on to
check that the contact changes state correctly.
Power feeds for all external devices may be connected to reduce battery consumption (if
batteries are used). Set
WARNING! If contact 22(SC) is used for the photocell test function or battery saving fun-
ction, a gate open indicator lamp cannot be connected.
The photocells FT2
–
. Photocell FT2 disabled when gate is opening.
–
. Photocell FT2 disabled when gate is closing.
–
. The gate opens when an open command is received if photocell FT2 is obstructed.
–
. NC (normally closed) incoming contact.
If the photocells are not installed, jumper the terminals 24(FT2) - 23(COM) or set the
parameters
and
WARNING! Use R90/F4ES, G90/F4ES or T90/F4S series photocells.
The photocells FT1
–
. Photocell triggers only during gate closure. Photocell is ignored during gate
opening.
–
. Movement is reversed if the photocell is triggered during gate closure.
–
. The gate opens when an open command is received if photocell FT1 is obstructed.
–
. NC (normally closed) incoming contact.
If the photocells are not installed, jumper the terminals 25(FT1) - 23(COM) or set the
parameters
and
WARNING! Use R90/F4ES, G90/F4ES or T90/F4S series photocells.
and
.
(24V
- duty cycle
max. 15 W
or
.
.
.
.
.
.
-
.
.
40 W
