Adjusting stop advance of MOTOR 1 when opening
Adjusting stop advance of MOTOR 2 when opening
The leaf stops against the opening stop.
A leaf stop advance of 1 to 25 motor turns before the completely open position may be set.
Setting automatic closing time
The timer starts from the gate open state and continues for the set time. Once the set time is reached, the gate closes
automatically. The timer count restarts if a photocell is triggered.
IMPORTANT: persistent activation of the opening command prevents automatic reclosure; the automatic reclosure time
count is resumed when the opening command is released.
Pause time settable from 00 to 90 s.
Pause time settable from 2 to 9 min.
Enabling of management for opening with automatic reclosure exclusion
If enabled, the exclusion of automatic reclosure only applies for the command selected via the parameter. For example:
if you set
, automatic reclosure is excluded following an AP command, but it is activated following a PP or PED
command.
NB: a command activates a manoeuvre in the open-stop-close or close-stop-open sequence.
Disabled.
An AP (opening) command activates the opening manoeuvre. With the gate fully open, automatic reclosure is excluded.
An AP (open) or CH (close) command activates the closure manoeuvre.
A PP (step mode) command activates the opening manoeuvre. With the gate fully open, automatic reclosure is excluded.
Another PP (step mode) command activates the closure manoeuvre.
A PED (partial opening) command activates the partial opening manoeuvre. Automatic reclosure is excluded. Another
PED (partial opening) command activates the closure manoeuvre.
Regulating the automatic closing time after opening pedestrian gate
The timer starts from the moment the gate is fully open; The timer count restarts if a photocell is triggered.
pause time settable from 00 to 90 s.
pause time settable from 2 to 9 min.
Adjusting opening delay (alignment) of MOTOR 2
During opening, MOTOR 2 starts with an adjustable delay after MOTOR 1.
From 0 to 10 s.
Adjusting closing delay (alignment) of MOTOR 1
During closing, MOTOR 1 starts with an adjustable delay after MOTOR 2.
From 0 to 30 s.
Setting reverse time after activation of sensing edge or obstacle detection (crush
prevention)
This sets the reverse manoeuvre time after activation of the sensing edge or the obstacle detection system.
From 0 to 60 s.
Select type of electric lock
Normally UNPOWERED electric lock (powered only for 3 s when opening starts).
N.B.: The electric lock is enabled by parameter
.
"ventouse" type electric block (normally powered when the gate is completely closed).
Not powered when gate is moving.
"ventouse" type electric block (normally powered when the gate is completely opened or completely closed).
Not powered when gate is moving.
Electric lock of normally NOT powered type, with adjustable timing
=0.5 seconds;
=1 second;
=1.5 seconds.
Enable electric lock
Disabled.
Enabled. When LEAF 1 approaches the gate closed stop, the controller delivers supplementary power to MOTOR 1 to
latch the electric lock.
Enabled. When LEAF 1 approaches the gate closed stop, the controller delivers maximum power to MOTOR 1 to latch
the electric lock. The obstacle detection system is disabled.
