MICRO-EPSILON thicknessCONTROL RTP 8301.EO Betriebsanleitung Seite 54

Bedienungsanleitung Software
PLC --> ME
Address
+0.1
+0.2
+0.3
+0.4
+0.5
+0.6
+0.7
+1.0
+1.1
+1.2
+1.3
+1.4
+1.5
+1.6
+1.7
+4.0
+8.0
+12.0
+16.0
+20.0
+24.0
+44.0
+48.0
+52.0
+56.0
+60.0
+64.0
+68.0
+72.0
+76.0
+80.0
+84.0
+88.0
thicknessCONTROL RTP 8301.EO / 4350039.85
Name
Enable Measurement
Start Measurement
Stop Measurement
Reset Length Calculation
Start Fix Position Measure-
ment
16 Bit Reserve
Thickness Setpoint
Thickness Upper Tolerance REAL
Thickness Lower Tolerance REAL
RecipeID
Position for Fix Position
Measurement
Type
Bit
Bit
Bit
Bit
Bit
Bit
Bit
Bit
Bit
Bit
Bit
Bit
Bit
Bit
Bit
REAL
Byte[20]
REAL
Description
1: measurement allowed
0: no measurement allo-
wed
1: start measurement (trig-
gered with edge 0_1)
1: stop measurement (trig-
gered with edge 0_1)
0_1: length calculation
reseted to zero
1: start fix position mea-
surement (triggered with
edge 0_1).
Can be stopped with bit
„Stop Measurement".
setpoint of thickness [mm]
upper tolerance of thick-
ness [mm] (absolut value)
lower tolerance of thick-
ness [mm] (absolut value)
recipe ID - array of bytes in
ASCII code
Position [mm] for fix positi-
on measurement. Position
is frome home position of
traversing motor.
