Technical Data - MICRO-EPSILON thicknessCONTROL RTP 8301.EO Betriebsanleitung

thicknessCONTROL TCP 8301.EO
Document version AA

5 Technical data

5.1 System
5.1.1 Characteristics of basic system
Characteristic
System type
Width measuring cell
Depth measuring cell
Height measuring cell
Height threading gap
Height measuring gap
Width measuring gap
Traversing speed
Speed data acquisition
Roller diameter, approx.
Wrap angle
Tempered roller
Roller compensation
Pneumatic cleaning system
Kind of the regular operator
interface (HMI)
Color
Enclosure
Cooling
Length signal
Type Emergency-Stop (ES)
ES HW-interface to the line
Printing time 25.07.2021 9:22
File name AFS 2.0 thickCON RTP 8301.EO-1000 Art.Nr. 4350039_1
Description and/or value
-1000
2000 mm
500 mm
900 mm
100 mm
12 mm
1200 mm
default : 10 m/min
4kHz
≤ 200mm
> 60°
X option 4350198
X
X
Set of Panel-IPC for Integration in the line control panel
X Touch screen
X Keyboard, Mouse
Alternative HM, see section 5.1.2
RAL 7035 light grey
IP 20
See section 0
No signal, display related to time
X Incremental sensor signal
via interface of the line
ES only at the system and no line integration
no ES at the system only line integration
X ES at the system and line integration
special ES (rope, protective door, light curtain)
X Reset central
Reset at the measuring system
X Connected by wiring
Max: 18 m/min
Page 5 of 31
