U–Series
23. U S
SED UBSTANCES
The unit does not release any silicone and is suitable for the use in paint shops.
The unit conforms to the RoHS directive 2002/96/EC.
Electrolytic capacitors included in this unit do not use electrolytes such as Quaternary Ammonium Salt Systems.
Plastic housings and other molded plastic materials are free of halogens.
The materials used in our production process do not include the following toxic chemicals:
Polychlorinated Biphenyl (PCB), Pentachlorophenol (PCP), Polychlorinated naphthalene (PCN), Polybrominated
Biphenyl (PBB), Polybrominated Biphenyl Oxide (PBO), Polybrominated Diphenyl Ether (PBDE), Polychlorinated
Diphenyl Ether (PCDE), Polybrominated Diphenyl Oxide (PBDO), Cadmium, Asbestos, Mercury, Silica
24. P D
HYSICAL IMENSIONS AND
Width 123mm / 4.84''
Height 124mm / 4.88''
Depth 119mm / 4.69''
Weight 2850g / 6.28lb
DIN-Rail Use 35mm heavy duty DIN-rails according to EN 60715 or EN 50022.
The DIN-rail height must be added to the depth (119mm) to calculate the total required installation
depth.
Electronic files with mechanical data can be downloaded at www.pulspower.com
Fig. 24-1 Side view
May. 2008 / Rev. 1.1 DS-UBC10.241-EN
All parameters are specified at an input voltage of 24V, 10A output load, 25°C ambient and after a 5 minutes run-in time
unless otherwise noted. It is assumed that the input power source can deliver a sufficient output current.
W
EIGHT
Plus height of signal connector plug and Spare fuse
Plus depth of DIN-rail
www.pulspower.com Phone +49 89 9278 0
UBC10.241, UBC10.241-N1
Fig. 24-2 Front view
Germany
24V, 10A, DC-UPS
