U–Series
17. EMC
The unit is suitable for applications in industrial environment as well as in residential, commercial and light industry
environment without any restrictions. CE mark is in conformance with EMC guideline 89/336/EC and 93/68/EC and the
low-voltage directive (LVD) 73/23/EC, 93/68/EC.
A detailed EMC Report is available on request.
EMC Immunity
Electrostatic discharge
Electromagnetic RF field
Fast transients (Burst)
Surge voltage
Conducted disturbance
*) DIN-Rail earthed
**) Tested with coupling clamp
EMC Emission
Conducted emission
Radiated emission
This device complies with FCC Part 15 rules.
Operation is subjected to the following two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause undesired operation.
*) Informative measurement with voltage probe
Switching frequencies
Switching frequency of boost converter
Switching frequency of electronic output current limitation
Switching frequency of battery charger
May. 2008 / Rev. 1.1 DS-UBC10.241-EN
All parameters are specified at an input voltage of 24V, 10A output load, 25°C ambient and after a 5 minutes run-in time
unless otherwise noted. It is assumed that the input power source can deliver a sufficient output current.
EN 61000-6-1, EN 61000-6-2
EN 61000-4-2
EN 61000-4-3
EN 61000-4-4
EN 61000-4-5
EN 61000-4-6
EN 61000-6-3, EN 61000-6-4
EN 55022
EN 55022
EN 55011, EN 55022
www.pulspower.com Phone +49 89 9278 0
UBC10.241, UBC10.241-N1
Generic standards
Contact discharge 8kV
Air discharge 15kV
80MHz-1GHz 10V/m
Out- and input lines 2kV
Signal lines **) 2kV
Output + - 500V
Input + - 500V
+ / - housing 500V
0,15-80MHz 10V
Generic standards
Input lines Class B *)
Output lines Class B *)
Class B
The DC-UPS has three converters with three different
switching frequencies included.
100kHz Constant frequency
78kHz Constant frequency
19.5kHz Constant frequency
Germany
24V, 10A, DC-UPS
Criterion A*)
Criterion A *)
Criterion A
Criterion A
Criterion A
Criterion A
Criterion A
Criterion A
Criterion A
14/23
