U–Series
1. G D
ENERAL ESCRIPTION
This uninterruptible power supply (UPS) controller
UBC10.241 with integrated battery is a compact
addition to standard 24V power supplies to bridge
power failures or voltage fluctuations. Expensive
downtimes, long restart cycles and loss of data can
be avoided.
The DC-UPS includes
management system which charges and monitors
the battery to achieve the longest battery service life
as well as many diagnostic functions that ensure a
reliable operation of the entire system.
A unique feature of the UBC10.241 is that only one
12V battery is required to buffer the 24V output.
This makes matching batteries unnecessary and
allows a precise battery charging and testing.
The UBC10.241 has one integrated 12V 5Ah high
current VRLA battery, which is easy to change.
In addition to the UBC10.241, a separate UPS
controller (UB10.241) which requires an external 12V
battery is available when a longer buffer time is
required.
3. O N
RDER UMBERS
DC-UPS
UBC10.241
UBC10.241-N1 Battery not assembled
Accessories UZB12.051
May. 2008 / Rev. 1.1 DS-UBC10.241-EN
All parameters are specified at an input voltage of 24V, 10A output load, 25°C ambient and after a 5 minutes run-in time
unless otherwise noted. It is assumed that the input power source can deliver a sufficient output current.
a professional battery
Standard unit
Battery 12V 5Ah
www.pulspower.com Phone +49 89 9278 0
UBC10.241, UBC10.241-N1
DC-UPS
WITH INTEGRATED BATTERY
■
Compact and Easy to Install
■
Longest Buffer Time in Class
■
Easy Battery Access
■
Stable Output Voltage in Buffer Mode
■
Superior Battery Management for Longest Battery Life
■
Temperature Compensated Battery Charging
■
Comprehensive Diagnostics and Monitoring Functions
■
Replace Battery Signal Included
■
Electronically Overload and Short Circuit Protected
■
50% Power Reserves
■
Selectable Buffer Time Limiter
2. S -
HORT FORM
Input voltage nom. 24Vdc
range 22.5-30Vdc
Output current min. 15A
min. 10A
Output voltage typ. 0.23V lower
as input voltage
22.25V
Integrated battery 12V 5Ah
Temperature range 0 to 40°C
Dimensions 123x124x119mm WxHxD
Buffer time typ. 16'15"
typ. 6'15"
Typical setup of a DC-UPS system with the UBC10.241:
AC
24V
Power
Supply
e.g.:
Dimension
4. M
ARKINGS
IND. CONT. EQ.
UL 60950-1
UL 508
R
C US
182790
Germany
24V, 10A, DC-UPS
D
ATA
Normal mode
Buffer mode
Normal mode
Buffer mode, 10A
VRLA lead acid
Operational
At 5A load
At 10A load
DC
24V 24V
DC-UPS Load
e.g.: PLC
UBC10.241
Class I Div 2
GL
EMC, LVD
Marine
1/23
