thicknessCONTROL TCP 8301.EO
Document version AA
7.4 Pneumatic supply network (only necessary, if cleaning system)
The Pneumatic connection from the system to the clients switchbox must be performed by the Cli-
ent. The current supply must conform to the characteristics specified in the following table.
Characteristic
Input pressure
Pressure deviation
Cleanliness
Connection
Printing time
25.07.2021 9:22
File name
AFS 2.0 thickCON RTP 8301.EO-1000 Art.Nr. 4350039_1
Value
6 bar
± 5 %
DIN ISO 8573-1, class 2, dew point max. 3°C (276.15 K), -40°C (233.15 K)
is suggested
FESTO KSS6 for fast connecting
Page 9 of 31
