2.3 – The features of the Apex ID and their functions
Feature
LCD Screen – Fig 2.1
Control panel – Fig 2.2
Stand – Fig 2.3
Battery compartment – Fig 2.4
Probe cord jack – Fig 2.5
Up button ( ) – Fig 2.6
Down button ( ) – Fig 2.7
SET
SET
Setting button ( ) – Fig 2.8
SET
SET
Power button ( ) – Fig 2.9
Buzzer volume signal – Fig 2.10
Graph signal – Fig 2.11
Battery signal – Fig 2.12
Root apex signal – Fig 2.13
Numeric signal – Fig 2.14
3 – PRO D U CT SYMBO L S
SN
Serial Number
REF
Part Number
Manufacturing Date
CE Marking
Type B Applied Part
Caution
EC REP
Functions
Shows the status of settings and indicates the distance
between the end of file inserted in root canal & root apex
Select power ON/OFF & control functions
Placing the Apex ID on a counter
Contains batteries 1.5V x 3 (DC 4.5V).
Connect to probe cord for measuring working length of
root canal
Push the button to increase the root apex standard value
by 0.1 and the volume of buzzer is increased 1 step up
Push the button to decrease the root apex standard value
by 0.1 and the volume of buzzer is decreased 1 step down
Push the button to fix the setting mode
Push the button to turn the unit ON/OFF
SN
Indicates the volume of the Buzzer
Graph shows the distance between the end of file and
root apex REF
Indicates remaining battery life
Indicates when file has reached the apical foramen, or
the "0" point set by the operator
Indicates the distance between the end of file & root apex
EC REP
Authorized Representative
in the European Community
Consult Instructions for Use
CSA Marking
Dispose of Properly
Manufacturer
