11.2 Wall mount bracket

Wall bracket with internal cable channel.
Fig. 88

11.3 Parapet bracket

Parapet bracket with internal cable channel.
Fig. 89
44
11.4 Power supply with
illuminator control
Weather-proof box with power supply and control of
the illuminators.
Fig. 90 Version of the standard box.
Fig. 91 Version of the UL certified box.
For further information refer to the relative
chapter (8.4.3 Connection of the alarm
inputs, of the twilight switch and of the
relays, page 23).
MNVCUPTMAXIR_1625_EN
