7890 Series GC Site Preparation

Heat Dissipation

Use
equipment. Maximums represent the heat given off when heated zones are set
for maximum temperatures.
Table 5 Heat dissipation
7890 Series GC
5975 Series MSD
5977 Series MSD
7010 or 7000 Triple Quad MS
7200 or 7250 Q-TOF MS
24
Table 5 to estimate the additional BTUs of heat dissipated from this
Oven type
Standard heater ramp
7681 BTU/hour maximum (8103 kJ/h)
Steady state, including MS interface
3000 BTU/hour (3165 kJ/h)
3000 BTU/hour (3165 kJ/h)
3700 BTU/hour (3904 kJ/h)
6200 BTU/hour (6541 kJ/h)
Fast oven ramp (option 002 or 003)
10,071 BTU/hour maximum
(10,626 kJ/h)
GC, GC/MS, and ALS Site Preparation Guide
