Power Consumption

Table 53
• The number and type of electrical outlets depend on the size and
• Power consumption and requirements depend on the country to which the
• The voltage requirements for your instrument are printed near the power
• The electrical outlet for the unit should have a dedicated ground.
• All instruments should be on a dedicated circuit.
• Power line conditioners should not be used with Agilent instruments.
Table 53 Power requirements
Product Oven type
7820A GC Standard
7820A GC Standard
7820A GC Standard
MSD
5975 Series MSD
5975 Series MSD
5975 Series MSD
5977 Series MSD
110
lists site power requirements.
complexity of the system.
unit ships.
cord attachment.
Line voltage (VAC)
100
single phase
(–10% / +10%)
120
single phase
(–10% / +10%)
200/220/230/240
single phase
(–10% / +10%)
120
(–10% / +5%)
220–240
(–10% / +5%)
200
(–10% / +5%)
120
(–10% / +5%)
Frequency Maximum
(Hz) continuous power
consumption (VA)
48–63 1500
48–63 2250
48–63 2250
50/60 ± 5% 1100 (400 for
foreline pump only)
50/60 ± 5% 1100 (400 for
foreline pump only)
50/60 ± 5% 1100 (400 for
foreline pump only)
50/60 ± 5% 1100 (400 for
foreline pump only)
GC, GC/MS, and ALS Site Preparation Guide
Current Power outlet
rating current rating
(amps)
12.5 15 Amp
Dedicated
18.8 20 Amp
Dedicated
9.6/9.3/ 10 Amp
9.3/9.2 Dedicated
8 10 Amp
Dedicated
8 10 Amp
Dedicated
8 10 Amp
Dedicated
8 10 Amp
Dedicated
