6850 Series GC Site Preparation

Dimensions and Weight

Select the laboratory bench space before the system arrives. Make sure the
area is clean, clear, and level. Pay special attention to the total height
requirements. Avoid bench space with overhanging shelves. See
The instrument needs space for proper convection of heat and ventilation.
Allow at least 25 cm (10 in) clearance between back of the instrument and wall
to dissipate hot air and allow for routine maintenance.
Table 31 Required instrument height, width, depth, and weight
Product
GC
6850 Series GCs
GC operational oven access
MSD
5975 Series MSD
• Diffusion pump
• Standard turbo pump
• Foreline pump
Standard
• GC/MS operational and maintenance access
5977 Series MSD
• Diffusion pump
• Performance turbo pump
• Performance CI/EI turbo pump
70
Height Width
51 cm (20 in) 29 cm (12 in)
34 cm (14 in) CO
37 cm (15 in) 6850
ALS
Requires ≥ 30 cm (12 in) open space above GC
41 cm (16 in) 30 cm (12 in)
41 cm (16 in) 30 cm (12 in)
21 cm (8 in) 13 cm (5 in)
Requires 30 cm (1 ft) to its left
41 cm (16 in) 30 cm (12 in)
41 cm (16 in) 30 cm (12 in)
41 cm (16 in) 30 cm (12 in)
Depth
57 cm (23 in)
2
54 cm (22 in)
54 cm (22 in)
31 cm (12 in)
54 cm (22 in)
54 cm (22 in)
54 cm (22 in)
GC, GC/MS, and ALS Site Preparation Guide
Table 31.
Weight
< 23 kg (51 lb)
39 kg (85 lb)
39 kg (85 lb)
11 kg (23.1 lb)
39 kg (85 lb)
41 kg (90 lb)
46 kg (100 lb)
