Power Consumption

Table 32
• The number and type of electrical outlets depend on the size and
• Power consumption and requirements depend on the country the unit ships
• The voltage requirements for your instrument are printed near the power
• The electrical outlet for the unit should have a dedicated ground.
• All instruments should be on a dedicated circuit.
Power line conditioners should not be used with Agilent instruments.
Table 32 Power requirements
Product Oven type
6850 Series GC Standard
6850 Series GC Standard
6850 Series GC Standard
6850 Series GC Fast
6850 Series GC Fast
6850 Series GC Fast
MSD
5975 Series MSD
GC, GC/MS, and ALS Site Preparation Guide
lists site power requirements.
complexity of the system.
to.
cord attachment.
Line voltage (VAC)
Japan: 100
single phase
(–10% / +10%)
Americas: 120
single phase
(–10% / +10%)
230
single/split phase
(–10% / +10%)
120 single phase
(–10% / +10%)
220/230/240
single/split phase
(–10% / +10%)
200/208
single/split phase
(–10% / +10%)
120
(–10% / +5%)
Frequency Maximum
(Hz) continuous power
consumption (VA)
48–63 1440
48–63 1440
48–63 2000
48–63 2400
48–63 2400
48–63 2400
50/60 ± 5% 1100 (400 for
foreline pump only)
6850 Series GC Site Preparation
Current Power outlet
rating current rating
(amps)
15 15 Amp
Dedicated
12 15 Amp
Dedicated
9 10 Amp
Dedicated
20 20 Amp
Dedicated
11 15 Amp
Dedicated
12 15 Amp
Dedicated
8 10 Amp
Dedicated
