Table 2 Required instrument height, width, depth, and weight (continued)
Product
• Foreline pump
Standard
Oil-free (MVP-070)
Oil-free (IDP3)
• GC/MS operational and maintenance access
MS
7010 and 7000 Triple Quad MS
• EI Mainframe
• EI/CI Mainframe
• Foreline pump
• GC/MS operational and maintenance access
7200 Q-TOF MS
• Mainframe
• Foreline pump
7250 Q-TOF MS
• Mainframe
• Foreline pump DS202
• Foreline pump IDP-15
• GC/Q-TOF operational and maintenance access
ALS
• GC with 7693A ALS injector
• GC with 7693A ALS tray
GC, GC/MS, and ALS Site Preparation Guide
Height Width
21 cm (8 in) 13 cm (5 in)
19 cm (7.5 in) 32 cm (13 in)
18 cm (7 in) 35 cm (14 in)
Requires 30 cm (1 ft) to its left
47 cm (18.5 in) 35 cm (14 in)
47 cm (18.5 in) 35 cm (14 in)
28 cm (11 in) 18 cm (7 in)
Requires 30 cm (1 ft) to its left
133 cm (52.5 in) 90 cm (34.5 in)
28 cm (11 in) 18 cm (7 in)
190 cm (74.8 in) 90 cm (34.5 in)
28 cm (11 in) 18 cm (7 in)
36.4 cm (14.3 in) 33.3 cm (13.1 in)
Requires 40 cm (16 in) on both sides, and 30 cm (12 in) in the
back.
Requires 50 cm (19.5 in) above the GC
Requires 43 cm (16.8 in) left of the GC
Requires 4.2 cm (1.7 inch) in front of GC
7890 Series GC Site Preparation
Depth Weight
31 cm (12 in) 11 kg (23.1 lb)
28 cm (11 in) 16 kg (35.2 lb)
14 cm (6 in) 10 kg (21 lb)
86 cm (34 in) 59 kg (130 lb)
86 cm (34 in) 63.5 kg (140 lb)
35 cm (14 in) 21.5 kg (47.3 lb)
100 cm (39.5 in) 138 kg (305 lbs)
35 cm (14 in) 21.5 kg (47.3 lb)
100 cm (39.5 in) 138 kg (350 lbs)
35 cm (14 in) 21.5 kg (47.3 lbs)
48.5 cm (19.1 in) 45.5 kg (100 lbs)
3.9 kg (8,6 lb)
each
6.8 kg (15 lb)
each
