7693A and 7650 Automatic Liquid Sampler Site Preparation

Dimensions and Weight

Select the laboratory bench space before the system arrives. Pay special
attention to the total height requirements. Avoid bench space with
overhanging shelves. See
Table 69 Required height, width, depth, and weight
Product
G4513A Injector
1
G4514A Tray
1
G4515A Bar Code Reader
G4522A Cooling Accessory
7650A Injector
Additional space requirements
• GC with 7693A ALS injector
• GC with 7693A ALS tray
• GC with 7650 ALS injector
1 The G4520A Tray with a bar code reader is available with a G4514A Tray and G4515A bar code reader.
140
Table 69.
Height (cm) Width (cm)
51 16.5
29 44
not applicable not applicable
not applicable not applicable
51 22
Requires 50 cm (19.5 in) above the GC
Requires 45 cm (17.5 in) left of the GC
Requires 50 cm (19.5 in) above the GC
Requires 9 cm (3.6 in) in front of the GC
Requires 3 cm (1.2 in) to the left of the GC
Depth (cm)
16.5
43
not applicable
not applicable
24
GC, GC/MS, and ALS Site Preparation Guide
Weight (kg)
3.9
6.8
0.3
2.2
(plus water
weight)
4.5
