Gas Supplies

General requirements

Supply instrument gases using tanks, an internal distribution system, or gas
generators. If used, tanks require two-stage pressure regulators with packless,
stainless steel diaphragms. The instrument requires 1/8-inch Swagelok
connections to its gas supply fittings. See
Plumb the gas supply tubing/regulators so that one 1/8-inch Swagelok female connector is
N O T E
available for each gas needed at the instrument.
Table 11
regulators are supplied with the 1/8-inch Swagelok female connector.
Table 11
Gas type
Air
Industrial Air
Hydrogen, Argon/Methane
Oxygen
Helium, Argon, Nitrogen
Table 12
inlets and detectors, measured at the bulkhead fittings on the back of the
instrument.
GC, GC/MS, and ALS Site Preparation Guide
lists available Agilent two-stage tank regulators. All Agilent
Tank regulators
CGA number
346
590
350
540
580
and Table 14 list minimum and maximum delivery pressures for
7890 Series GC Site Preparation
Figure 12.
Max pressure
125 psig (8.6 Bar)
125 psig (8.6 Bar)
125 psig (8.6 Bar)
125 psig (8.6 Bar)
125 psig (8.6 Bar)
Part number
5183-4641
5183-4645
5183-4642
5183-4643
5183-4644
35
