7890 Series GC Site Preparation

Maximum Length of Cables and Hoses

The distance between system modules may be limited by some of the cabling
and the vent or vacuum hoses.
• The length of the Agilent-supplied remote cable is 2 meters (6.6 feet).
• The length of the Agilent-supplied LAN cable is 10 meters (32.8 feet).
• The lengths of the power cords are 2 meters (6.6 feet).
• A quadrupole GC/MS system foreline pump can be located on the
The supporting surface for the 7200/7250 Q-TOF GC/MS system should be kept
C A U T I O N
relatively vibration free. Do not put the rough pump on your laboratory bench with the
7200/7250 Q-TOF GC/MS due to the vibration that the pump creates. Vibration can
lead to a loss of mass accuracy and resolution.
• A Q-TOF MS system foreline pump should be located on the floor. It must be
56
laboratory bench or on the floor. It must be close to the MS because it is
connected by a hose. The hose is stiff and cannot be bent sharply. The
length of the vacuum hose is 130 cm (4.24 feet) from the high vacuum pump
to the foreline pump, while the length of the foreline pump power cord is
2 meters (6.6 feet).
close to the MS because it is connected by a hose. The hose is stiff and
cannot be bent sharply. The length of the vacuum hose is 130 cm (4.24 feet)
from the high vacuum pump to the foreline pump, while the length of the
foreline pump power cord is 2 meters (6.6 feet).
GC, GC/MS, and ALS Site Preparation Guide
