Gas Supplies

Supply instrument gases using tanks, an internal distribution system, or gas
generators. If used, tanks require two-stage pressure regulators with packless,
stainless steel diaphragms. The instrument requires 1/8-inch Swagelok
connections to its gas supply fittings.
Plumb the gas supply tubing/regulators so that one 1/8-inch Swagelok female connector is
N O T E
available for each gas needed at the instrument.
Table 40
regulators are supplied with the 1/8-inch Swagelok female connector.
Table 40
Gas type
Air
Hydrogen, Argon/Methane
Oxygen
Helium, Argon, Nitrogen
Air
Table 41
inlets and detectors, measured at the bulkhead fittings on the back of the
instrument.
Table 41 Delivery pressures for inlets required at the GC/MS, in kPa (psig)
Inlet type
Split/Splitless 150 psi
Carrier (max) 1,172 (170)
Carrier (min) (20 psi) above pressure used in method
GC, GC/MS, and ALS Site Preparation Guide
lists available Agilent two-stage tank regulators. All Agilent
Tank regulators
CGA number
346
350
540
580
590
and Table 42 list minimum and maximum delivery pressures for
Split/Splitless 100 psi
827 (120)
6850 Series GC Site Preparation
Max pressure
125 psig (8.6 Bar)
125 psig (8.6 Bar)
125 psig (8.6 Bar)
125 psig (8.6 Bar)
125 psig (8.6 Bar)
On-column Purged packed
827 (120) 827 (120)
Part number
5183-4641
5183-4642
5183-4643
5183-4644
5183-4645
PTV
827 (120)
