7890 Series GC Site Preparation
Table 3 Power requirements (continued)
Product Oven type
5975 Series MSD
5977 Series MSD
5977 Series MSD
5977 Series MSD
MS
7010 or 7000 Triple Quad MS
7010 or 7000 Triple Quad MS
7010 or 7000 Triple Quad MS
7200 or 7250 Q-TOF MS
All
Data system PC
(monitor, CPU, printer)
1 Option 003, 208 VAC fast oven, uses a 220 VAC unit with operating range of 198 to 242 VAC. Most labs have 4-wire service
resulting in 208 VAC at the wall receptacle. It is important to measure the line voltage at the receptacle for the GC.
Do not use extension cords with Agilent instruments. Extension cords normally are
WA R N I N G
not rated to carry enough power and can be a safety hazard.
Although your GC should arrive ready for operation in your country, compare
its voltage requirements with those listed in
ordered is not suitable for your installation, contact Agilent Technologies.
Note that ALS instruments receive their power from the GC.
20
Line voltage (VAC) Frequency
(Hz)
200 50/60 ± 5%
(–10% / +5%)
120 50/60 ± 5%
(–10% / +5%)
220–240 50/60 ± 5%
(–10% / +5%)
200 50/60 ± 5%
(–10% / +5%)
120 50/60 ± 5%
(–10% / +5%)
220–240 50/60 ± 5%
(–10% / +5%)
200 50/60 ± 5%
(–10% / +5%)
200–240 50/60 ± 5%
(–10% / +5%)
100/120/200-240 50/60 ± 5%
(–10% / +5%)
Maximum Current
continuous power rating
consumption (VA) (amps)
1100 (400 for 8
foreline pump only)
1100 (400 for 8
foreline pump only)
1100 (400 for 8
foreline pump only)
1100 (400 for 8
foreline pump only)
1600 15
1600 15
1600 15
1800 (1200 for 15
foreline pump)
1000 15
Table 3. If the voltage option you
GC, GC/MS, and ALS Site Preparation Guide
Power outlet
current rating
10 Amp
Dedicated
10 Amp
Dedicated
10 Amp
Dedicated
10 Amp
Dedicated
15 Amp
Dedicated
15 Amp
Dedicated
15 Amp
Dedicated
15 Amp
Dedicated
15 Amp
Dedicated
