7890 Series GC Site Preparation
Table 2 Required instrument height, width, depth, and weight (continued)
Product
• GC with 7650A ALS injector
• GC with 7683B ALS injector
• GC with 7683B ALS tray
A system that includes a 7890 Series GC, a 5977, 5975, 7010 or 7000 MS, an
ALS, and a computer would require about 168 cm (5.5 ft) of bench space (see
Figure
would require about 206 cm (6.7 ft) of bench space (or 148 cm [4.8 ft]
excluding the area under the tray.) See
access and a printer, a total of 260 cm (8.5 ft) of bench space should be
available for a quadrupole GC/MS system and 298 cm (9.7 ft) should be
available for an Ion Trap GC/MS system. Some repairs to the GC/MS or to the
GC will also require access to the back of the instrument(s).
14
Height
1). A 7890 Series system with a GC, Ion Trap MS, ALS, and computer
Width Depth
Requires 50 cm (19.5 in) above the GC
Requires 43.3 cm (17 in) above the GC
Requires 30 cm (12 in) left of the GC
Figure 3. Allowing for operational
GC, GC/MS, and ALS Site Preparation Guide
Weight
3.9 kg (8,6 lb)
each
3.1 kg (7 lb) each
3.0 kg (7 lb)
