Table 53 Power requirements (continued)
Product Oven type
5977 Series MSD
5977 Series MSD
All
Data system PC
(monitor, CPU, printer)
Do not use extension cords with Agilent instruments. Extension cords normally are
WA R N I N G
not rated to carry enough power and can be a safety hazard.
Although your GC should arrive ready for operation in your country, compare
its voltage requirements with those listed in
ordered is not suitable for your installation, contact Agilent Technologies.
Note that ALS instruments receive their power from the GC.

Grounding

A proper earth ground is required for GC operations. Any interruption of the grounding
C A U T I O N
conductor or disconnection of the power cord could cause a shock that could result in
personal injury.
To protect users, the metal instrument panels and cabinet are grounded
through the three-conductor power line cord in accordance with International
Electrotechnical Commission (IEC) requirements.
GC, GC/MS, and ALS Site Preparation Guide
Line voltage (VAC) Frequency
(Hz)
220–240 50/60 ± 5%
(–10% / +5%)
200 50/60 ± 5%
(–10% / +5%)
100/120/200-240 50/60 ± 5%
(–10% / +5%)
7820 MSD Site Preparation
Maximum Current
continuous power rating
consumption (VA) (amps)
1100 (400 for 8
foreline pump only)
1100 (400 for 8
foreline pump only)
1000 15
Table 27. If the voltage option you
Power outlet
current rating
10 Amp
Dedicated
10 Amp
Dedicated
15 Amp
Dedicated
111
