Power Consumption

Table 3
• The number and type of electrical outlets depend on the size and
• Power consumption and requirements depend on the country to which the
• The voltage requirements for your instrument are printed near the power
• The electrical outlet for the unit should have a dedicated ground.
• All instruments should be on a dedicated circuit.
• Power line conditioners should not be used with Agilent instruments.
Table 3 Power requirements
Product Oven type
7890 Series GC Standard
7890 Series GC Standard
7890 Series GC Fast
7890 Series GC Fast
MSD
5975 Series MSD
5975 Series MSD
GC, GC/MS, and ALS Site Preparation Guide
lists site power requirements.
complexity of the system.
unit ships.
cord attachment.
Line voltage (VAC)
Americas: 120
single phase
(–10% / +10%)
220/230/240
single/split phase
(–10% / +10%)
Japan 200
split phase
(–10% / +10%)
220/230/240
single/split phase
1
(–10% / +10%)
120
(–10% / +5%)
220–240
(–10% / +5%)
Frequency Maximum
(Hz) continuous power
consumption (VA)
48–63 2250
48–63 2250
48–63 2950
48–63 2950
50/60 ± 5% 1100 (400 for
foreline pump only)
50/60 ± 5% 1100 (400 for
foreline pump only)
7890 Series GC Site Preparation
Current Power outlet
rating current rating
(amps)
18.8 20 Amp
Dedicated
10.2/9.8/ 10 Amp
9.4 Dedicated
14.8 15 Amp
Dedicated
13.4/12.8 15 Amp
/ 12.3 Dedicated
8 10 Amp
Dedicated
8 10 Amp
Dedicated
