Parameterbeschreibung
13-10 Vergleicher-Operand
Array [6]
Option:
[13] Analogeingang 54
[14] Interne 10V
3 3
[15] Interne 24V
[17] Steuerk.Temperatur
[18] Pulseingang 29
[19] Pulseingang 33
[20] Alarmnummer
[21] Warnnummer
[22] Analogeing. X30/11
[23] Analogeing. X30/12
[24] Sensorless Flow
[25] Sensorless Pressure
[30] Zähler A
[31] Zähler B
[34] Analog Input x48/2
[35] Temp Input x48/4
[36] Temp Input x48/7
[37] Temp Input x48/10
[40] Analogeingang X42/1
[41] Analogeingang X42/3
[42] Analogeingang X42/5
[46] AI53 scaled
[47] AI54 scaled
[48] AI53 unit
[49] AI54 unit
[50] FALSCH
[51] TRUE
[52] Steuer. bereit
[53] FU bereit
[54] Running
[55] Reversierung
[56] Im Bereich
[60] Ist=Sollwert
[61] Unter Min.-Sollwert
[62] Über Max.-Sollwert
[65] Torque limit
[66] Stromgrenze
[67] Out of current range
[68] Unter Min.-Strom
[69] Über Max.-Strom
[70] Out of speed range
[71] Unter Min.-Drehzahl
[72] Über Max.-Drehzahl
[75] Out of feedback range
[76] Unter Min.-Istwert
[77] Über Max.-Istwert
[80] Warnung Übertemp.
[82] Mains out of range
[85] Warnung
[86] Alarm (Abschaltung)
[87] Alarm (Absch.verrgl.)
118
®
VLT AQUA Drive FC 202
Funktion:
Danfoss A/S © 08/2015 Alle Rechte vorbehalten.
13-10 Vergleicher-Operand
Array [6]
Option: Funktion:
[90] Bus OK
[91] Mom.grenze u. Stopp
[92] Brake fault (IGBT)
[94] Safe stop active
[100] Vergleicher 0
[101] Vergleicher 1
[102] Vergleicher 2
[103] Vergleicher 3
[104] Vergleicher 4
[105] Vergleicher 5
[110] Logikregel 0
[111] Logikregel 1
[112] Logikregel 2
[113] Logikregel 3
[114] Logikregel 4
[115] Logikregel 5
[120] Timeout 0
[121] Timeout 1
[122] Timeout 2
[123] Timeout 3
[124] Timeout 4
[125] Timeout 5
[126] Timeout 6
[127] Timeout 7
[130] Digitaleingang 18
[131] Digitaleingang 19
[132] Digitaleingang 27
[133] Digitaleingang 29
[134] Digitaleingang 32
[135] Digitaleingang 33
[150] SL-Digitalausgang A
[151] SL digital output B
[152] SL digital output C
[153] SL digital output D
[154] SL digital output E
[155] SL digital output F
[160] Relais 1
[161] Relais 2
[162] Relay 3
[163] Relay 4
[164] Relay 5
[165] Relay 6
[166] Relay 7
[167] Relay 8
[168] Relay 9
[180] Hand-Sollwert aktiv
[181] Remote reference
active
[182] Startbefehl
[183] FU gestoppt
[185] Handbetrieb
