When the master unit is in protection, only the master unit stops and the
other units carry on working.
When a slave unit is in protection, this unit stops and the other units are
not involved.
If the master unit fails, the slave units also stop working.
Temperature sensors
All temperature sensors are classed as faulty when the voltage on the
corresponding input is lower than 0.05 V or higher than 4.95 V.
After an error has been signalled, all units stop. The error is eliminated
after the sensor has been restored.

Error code

1E5 Condenser temperature probe T3A fault
1Eb Antifreeze probe Taf1 fault
1Ed Compressor discharge temperature probe A
1EE Refrigerant temperature probe T6A
1F0 IPM module communication error
1F3 Fan A communication error
1F4 Protection L0 or L1 intervention 3 times in 60 minutes
1F6 Circuit A bus voltage (PTC)
1F9
1FF
1H9 Compressor driver A - configuration error
1HE
Winter anti-freeze protection, insufficient electric
1Pb
1PP IPM module error, circuit A
1PU
2E0 EEPROM error - inverter A module
2E5 Condenser temperature probe T3B fault
2E9 Water pressure detection failure
2Eb Antifreeze probe Taf2 fault
2Ed Compressor discharge temperature probe B
2EE Refrigerant temperature probe T6B
2F0 IPM module communication error.
2F3 Fan B communication error
2F4 Protection L0 or L1 intervention 3 times in 60 minutes
2F6 Circuit B bus voltage (PTC)
2F9
2FF
2H9 Compressor driver B - configuration error
2HE
Winter anti-freeze protection electric heating is
2Pb
seriously insufficient reminder
2PP IPM module error, circuit B
2PU
3E0 EEPROM error - inverter B module
3F3 Fan C communication error
3FF
3HE
3PU
C7
dF
E0 EEPROM error - main board
E1 Phases sequence - control from main board
Communication error between main board and
E2 keyboard / communication error between master and
slave (slave displays E2)
CS3000 AWP – 6721852570 (2022/11)
Description
Faulty probe Tfin1
Fan A motor failure
Valve A error
heating reminder
Fan A module
Faulty probe Tfin2
Fan B motor failure
Valve B error
Fan B module
Fan C motor failure
Valve C error
Fan C module
3 times PL
Defrosting
Error code
"Total" outlet water temperature probe Tw fault (only for
E3
E4 Outlet water temperature probe Two fault
E6 Storage temperature probe T5 fault
E7 Room temperature probe T4 fault
E8
E9 Water flow detection failure
EC Slave unit module reduction
EF Return water temperature probe
EH
EP Drain temperature probe
EU Condenser total temperature probe Tz
F2 Low DSH (discharge super-heating)
Fb
Fd Faulty suction temperature probe (Refrigerant side)
FP DIP switch for modular unit configuration error
H5
L0
L1
L2
L4
L5 Compressor speed error
L7
L8 Variation of frequency higher than 15Hz
L9 Difference of phase frequency higher than 15Hz
P0 High pressure / drain temperature
P1
P2 Total condenser output high temperature Tz
P4 Compressor A in protection
P5 Compressor B in protection
P6
P7 Condenser high temperature
P8
P9 Inlet / outlet water temperature difference
PA
Pb
PC Evaporator low pressure in cooling
Antifreeze protection evaporator low temperature in
PE
PF Circuit board lock - controller lock/unlock error
PH High room temperature probe T4
PL Tfin module, high temperature
Table 52
Troubleshooting
Description
master unit)
Phases sequence
Auto-test error
Faulty pressure sensor
High / low voltage
Module protection
Low voltage
High voltage
MCE error
No phase
Low pressure
Module error
Reserved
Reserved
Winter antifreeze
cooling
