EN 12

4.5 Accessories container

In the accessories container below the working
chamber, you can store blanks, tools, and the spindle
service set ready to hand.
To access the accessories container, manually pull it
out of the machine.
F . 5 O
IG PENING THE ACCESSORIES CONTAINER
F . 6 A (
IG CCESSORIES CONTAINER BLANKS AND TOOLS NOT PROVIDED
To close the accessories container, push it into the
machine until it is completely closed.

4.6 Anti-soiling concept

The anti-soling concept decreases the soiling and wear
of sensitive machine parts.
The anti-soiling concept does not replace the regular
cleaning of the machine. Without regular cleaning, the
machine life decreases significantly.
extraction system
When dry machining, an operational external air extrac-
tion system must be installed. Otherwise, the machine
will get soiled over time and become defective.
The anti-soiling concept consists of:

4.7 CAM computer

To operate the machine, you must use a computer
running Windows
designed software ("manufacturing software"). The
)
manufacturing software consists of the following
components:
To create and design the dental objects you also need
a CAD application (sold separately by specialist
dealers).
Original Operating Instructions: K5+
Version: 12/16/2021
K5+ – Machine overview
Machine damage when dry
NOTICE
machining without an air
Always use a correctly installed and operational
external air extraction system during dry machining.
The external air extraction system ‒ An
n
external suction unit creates a vacuum in the work-
ing chamber and extracts machining debris from
it.
n Air that is emitted into the working cham-
ber ‒ Blows machining debris away from the
spindle and other machine parts.
The internal vacuum sensor ‒ Constantly
n
monitors the vacuum in the working chamber.
The ionizer ‒ The ionizer electrically discharges
n
machining debris of certain materials to reduce
their distribution in the working chamber.
("CAM computer") and specially
®
DENTALCAM ‒ A CAM application for creating
n
and calculating virtual blanks ("jobs").
DENTALCNC ‒ A CNC application for machining
n
jobs and maintaining the machine.
