Byte Significance
0 Status byte
Zero setting (torque
and angle of rotation)
is only confirmed via
a brief pulse (10ms).
The following applies
for shunt: The bits
always represent the
actual status, which
may not correspond
to the specifications
1 Parameter set
2 Error status
measured values
TIM-EC
EtherCAT® data transmission and configuration
Protocol TIM-EC outgoing
Bit
0
1
2
3..7
0...6
7
0
1
2
A3704-4.0 HBM: public
Values Bit significance
0 No action
1 Zero setting torque active
0 No action
1 Zero setting angle of rotation
active
0 Shunt is off
1 Shunt is on
0 Reserved
0 Parameter set being
processed/edited
1..32 Parameter set selected and active
33-62 Not permitted/reserved
63 Factory setting is active
0 Parameter set unlocked
1 Parameter set locked by web
browser
0 No measured value error/Global
flag over all measurement
channels
1 Measured value error Md/N
Name: Global_Failure_Flag
0 Torque values TP 1 OK
1 Torque values TP 1 Faulty
Name: Torque_Failure_Flag1
0 Torque values TP 2 OK
1 Torque values TP 2 Faulty
Name: Torque_Failure_Flag2
