HBM TIM-EC Montageanleitung Seite 75

Selection
Pulses/revolution
Max. speed [rpm]
Type
Zero index
Angle of rotation resolution
Reset angle with
Max. angle [degree]
Angle offset [degree]
Angle interpolation
Glitch filter
Save
TIM-EC
The T40B/T40M torque transducer outputs as standard a
quadrature signal with 1024 pulses/revolution. Standard
settings are indicated by underlining.
Speed transducer
Manual/from torque transducer
Taken over by the transducer
With manual selection: 1-5000
Taken over by the transducer
With manual selection: 1-50000
If the maximum speed is exceeded by 5%, an
error flag is set in the fieldbus.
Taken over by the transducer
With manual selection: Quadrature ; Basic
Taken over by the transducer
With manual selection: Yes/No
1x; 2x; 4x
(4x is only available when type = Quadrature)
EtherCAT
360; 720; Max**
0 ... ±Max. angle**
On/Off
Off, 82ns, 1μs, 10μs, 100μs
Max. rpm
If this value is exceeded by 5%, an error flag is set in the
fieldbus.
A3704-4.0 HBM: public
®
; Manual; Zero index
Settings
73
