Low-pass filter 1
(-1 dB)
Low-pass filter 2
(-1 dB)
Unit
Decimal point
Sign
Unit
Decimal point
Sign
Low-pass filter 1
(-1 dB)
TIM-EC
0.1 Hz ; 1 Hz; 10 Hz; 100 Hz; 1 kHz; 3 kHz; CASMA-Filter;
Off
0.1 Hz ; 1 Hz; 10 Hz; 100 Hz; 1 kHz; 3 kHz; Off
Angle of rotation
Deg.
.;.0;.00;.000;.0000;.00000
Positive; negative
Power
W;kW;hp
.;.0;.00;.000;.0000;.00000
Positive; negative
0.1 Hz ; 1 Hz; 10 Hz; 100 Hz
Changes in the Units/Filter menu can only be imple­
mented when the activated parameter set is unlocked.
See Chapter 10.3.1 Passcode.
Notice
These data are only permanently saved when they are
saved to a parameter set in the menu Save parameters.
Otherwise the settings will be lost after switch on/off.
