10.4.2 User single sensor tracking (sNuh)

Triggers continuous measurement (tracking) of the distance and outputs the result immediately to the
serial interface. The distance measurement is executed as fast as possible (depending on target
conditions). The measured distance is corrected with the user offset and user gain as set with the
commands 10.5.2 "Set/Get user distance offset (sNuof)" on page 152 and 10.5.3 "Set/Get user
distance gain (sNuga)" on page 153. The measurements are continued until the "STOP/CLEAR
command (sNc)" is received by the device. Corresponding to the new measured distance value, the
statuses LEDs and digital outputs are updated.
This command takes the "Set/Get user distance offset (sNuof)" and "Set/Get user
distance gain (sNuga)" into account.
Command
Return successful
Return Error
Parameters
Printed in the Federal Republic of Germany
03/09/2016
•
Danger of physical injury and damage to property by undefined interface
states !
Never use these commands if more than one device is connected to
-
the RS-422 line.
Command
sNuh<trm>
gNuh+xxxxxxxx
<trm>
gN@Ezzz<trm>
Device ID (0..9)
N
xxxxxxxx Distance in 0.1 mm
Error code
zzz
