Command set

10.3.3 Set auto start configuration (sNA)

This command activates the stand-alone mode with auto start of the LLB measuring system. It triggers
continuous measurements of the distance. The analog, digital and SSI outputs are updated according
to the measured distance values. The sampling time defines the measurement rate. If the sampling
time is set to zero, the measurements are executed as fast as possible (depending on target
conditions).
The stand-alone mode with auto start is active until the STOP/CLEAR command (
the device.
●
The operating mode is stored in the LLB and activated immediately. This mode is
also activated after next power ON.
●
Internally "tracking with buffering" is started (command sNf). Therefore the last
measurement can also be read out from the device with the command sNq.
Command
Return successful
Return Error
Parameters

10.3.4 Analog output

10.3.4.1 Set/Get analog output min level (sNvm)

This command sets the minimum analog output current level (0 or 4 mA).
Command
Return successful
Return Error
Parameters
Configuration parameters must be saved (see 10.3.8 "Save configuration parameters (sNs)" on page 145).
 TR-Electronic GmbH 2011, All Rights Reserved
Page 138 of 156
Command
sNA+xxxxxxxx<trm>
gNA?
<trm>
gN@Ezzz<trm>
Device ID (0..9)
N
Sampling time in 10 ms (if 0 -> max possible sampling rate)
xxxxxxxx
Error code
zzz
Set Command
sNvm+x<trm>
gNvm?
<trm>
gN@Ezzz<trm>
Device ID (0..9)
N
Minimum output for analog out
x
0: Minimum current is 0 mA
1: Minimum current is 4 mA
Error code
zzz
TR - ELE - BA - DGB - 0021 - 06
sNc
Get Command
sNvm<trm>
gNvm+x
<trm>
gN@Ezzz<trm>
Printed in the Federal Republic of Germany
) is received by
