MessageType: I-Profil
Feldname
MessageType
ConfigMode active
Time is synced by NTP
Values are valid
Alarm
Quality
MeasurementRateHz
TimestampSeconds
TimestampMicroSeconds 14
EncoderValue
ProfilLength
Profile_x_coordinate_[0]
Profile_Intensity_[0]
...
Profile_x_coordinate_[n] 24 + (a × n)
Profile_Intensity_[n]
V4 | OX200 (ab Firmware 1.6.0)
Offset
Value Datentyp Beschreibung
0
2
1
2
3
4
5
6
10
18
20
24
26 (16Bit)/
28 (32Bit)
24 + (a × n) + z
Betriebsanleitung
Schnittstellen und Protokolle
UInt8
0 = Messwerte
1 = Z-Profil 16Bit
2 = I-Profil 16Bit
3 = Z-I-Profil 16Bit
129 = Z-Profil 32Bit
130 = I-Profil 32Bit
131 = Z-I-Profil 32Bit
Bool
Bool
Bool
Bool
UInt8
Float32
UInt32
UInt32
UInt16
UInt32
Anzahl der Profilpunkte.
Int16/
Int32
UInt16/
UInt32
Int16/
a = 4 (16Bit) oder a = 8 (32Bit)
Int32
n = ProfilLength -1
UInt16/
z = 2 (16Bit) oder z = 4 (32Bit)
UInt32
|
5
47
