1. GENERAL

Read this documentation carefully before installation.
1.1 Applications
ACTIVE is a compact pressure boosting system composed of a pump, a motor and a built-in control unit, which can also be installed outside.
It is used in particular for increasing the pressure in storage tanks and for water supply:
- in domestic pressure boosting systems,
- for small farming and gardening applications,
- for industrial services and systems,
- for washing systems and hobby applications.
The pump can be used for pumping rainwater, drinking water and non drinking water.

2. PUMPED FLUIDS

The machine has been designed and built for pumping water, free from explosive substances and solid particles or fibres, with a density of
1000 kg/m³ and a kinematic viscosity of 1 mm²/s, and chemically non-aggressive liquids.
Small sand impurities of 5-10 gr./m³ - Ø 1 mm are accepted.

3. TECHNICAL DATA

3.1 Electrical data
- Supply voltage:
- Max. current:
- Degree of protection:
- Insulation class:
- Power cable:
3.3 Description of model properties
Pump model Active J
Characteristics
Applications with water from an artesian well or underground tank
Limitations
Installation
conditions
Particular
suitable for
characteristics
pumping water
containing air
1x220-240V 50/60Hz
6,5 A
IP55 Active - IP44 Motor
F
1,5 mt H05 RN-F with/without plug
Active JI
Self-priming
suction up to 8 metres
with foot valve
stainless suitable
for pumping water
containing air
ENGLISH
3.2 Operating conditions
- Range of operation:
- Head up - Hmax (m):
- Liquid temperature:
- Environment temperature:
- Storage temperature:
- Maximum working pressure:
- Relative humidity in air:
- Connections:
- Noise level:
Active JC Active E
centrifugal
pressurization for
domestic use
water without
dissolved gases
below head
hydraulic,
technopolymer
suitable for silent running
pumping water
containing air
17
0,3 ÷ 8,4 m³/h
page 147
0 ÷ 35°C domestic use
(EN 60335-2-41)
0 ÷ 40°C
-10 ÷ 40°C
8 bar (800 Kpa)
Max. 95%
1" GAS / NPT
Directive EC 89/392/CEE
Active EI Active EC
centrifugal
centrifugal
self-priming
with water from an
pressurization for
artesian well or
domestic use
underground tank
suction up to 8 water without
metres dissolved gases
with foot valve below head
silent running and
hydraulic,
stainless , suitable
technopolymer,
for pumping water
silent running
containing air
