1. Introduction
Manufacturer:
Scheppach GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear Customer,
We hope your new product brings you much enjoy-
ment and success.
Note:
In accordance with the applicable product liability
laws, the manufacturer of this product assumes no lia-
bility for damage to the product or caused by the prod-
uct arising from:
• Improper handling,
• Failure to comply with the operating manual,
• Repairs carried out by third parties, unauthorised
specialists,
• Installing and replacing non-original spare parts,
• Improper use,
• Failures of the electrical system in the event of the
electrical regulations and VDE provisions 0100, DIN
57113 / VDE0113 not being observed.
Note:
The operating manual is part of this product. It includes
important instructions for the safe, proper and econom-
ic operation of the product, for avoiding danger, for min-
imising repair costs and downtimes and for increasing
the reliability and extending the service life of the prod-
uct. In addition to the safety instructions in this operat-
ing manual, you must also observe the regulations ap-
plicable to the operation of the product in your country.
Familiarise yourself with all operating and safety in-
structions before using the product. Only operate the
product as described and for the specified areas of ap-
plication. Keep the operating manual in a good place
and hand over all documents when passing the product
on to third parties.
2. Product description (Fig. 1 - 21)
1. Handle
2. Engine brake lever
3. Lower push bar
4. Plastic star grip nut
5. Catch basket
6. Discharge flap
7. Belt cover
28 | GB
7a. Phillips screw
7b. Allen screw
8. Wheels
8a. Wheel caps
8b. Collar nuts
9. Oil dipstick
9a. Oil drain screw
10. Working height adjustment
11. Fuel filler cap
12. Air filter cover
12a. Wing nut
13. Pull starter
14. Tensioning pulley
14a. Securing nut
14b. V-belt
15. Main switch
16. Fuel valve
17. Choke lever
18. Nut
18a. Lock nut
19. Spark plug connector
19a. Spark plug
A. Cable clamp
B. Pull cord holder
C. Bolt screw
D. Securing nut
E. Square neck screw M8x30
F. Flat head screw M8x45
G. Washer
3. Scope of delivery (Fig. 2)
Item
3
4
5
8
8 a
A
B
C
D
E
F
G
www.scheppach.com
Quantity Designation
2x Lower push bar
4x Plastic star grip nut
1x Catch basket
4x Wheels
4x Wheel cap
1x Cable clamp
1x Pull cord holder
2x Bolt screw
2x Securing nut
2x Square neck screw M8x30
2x Flat head screw M8x45
4x Washer
