OPERATING INSTRUCTIONS
2 General safety notes
2.1 Qualification of personnel
en
2.2 Intended use
3 Product description
3.1 Product identification via the SICK product ID
24 O P E R A T I N G I N S T R U C T I O N S | W4F MultiPulse
Instructions to action
The arrow denotes instructions to action.
►
1. The sequence of instructions is numbered.
2. Follow the order in which the numbered instructions are given.
✓
The tick denotes the results of an action.
Connection, mounting and configuration of the product must only be car‐
ried out by qualified personnel.
This product does not constitute a safety component as defined in the
NO
Machinery Directive.
2006/42/EC
SAFETY
Do not install the product in places exposed to direct UV radiation (sun‐
light) or other weather conditions.
The product must be adequately protected against moisture and contami‐
nation.
Any work on the product may only be carried out by personnel qualified and authorized
to do so.
Qualified personnel are able to perform tasks assigned to them and can independently
recognize and avoid any potential hazards. This requires, for example:
• technical training
• experience
• knowledge of the applicable regulations and standards
The MultiPulse sensor is an opto-electronic photoelectric proximity sensor with back‐
ground suppression (referred to as "sensor" or "product" in the following) for the
optical, non-contact detection of objects, animals, and persons.
The MultiPulse sensor features self-monitoring when the object is detected. The output
of the sensor oscillates at 2 Hz / 10 Hz (depends on variant) during object detection.
The sensor alone is not a safety component in terms of the Machinery Directive. If it is
integrated in a safety solution, a responsible organization (e.g. TÜV) can approve it.
If the product is used for any other purpose or modified in any way, any warranty claim
against SICK AG shall become void.
SICK product ID
The SICK product ID uniquely identifies the product. It also serves as the address of the
web page with information on the product.
The SICK product ID comprises the host name pid.sick.com, the part number (P/N),
and the serial number (S/N), each separated by a forward slash.
