Base scaffold with first extension element
This picture shows the
completely mounted
scaffold with base scaffold,
first extension element and
8 ballast weights.
NOTE:
Free-standing scaffolds must be secured against tilting with ballasts, outriggers and
stabilizing sets. For details regarding the number of required ballasts and outriggers,
refer to the table on page 67.
The picture shows a ballast
element on the stabilizer.
For details, see page 67
The picture shows an
attached outrigger.
For details, see page 67
The picture shows how to
adjust a stabilizing set.
For details, see page 68
Base scaffold with first extension element
